YG Acoustics™’ Rack series was initially designed as a tool for internal use. The factory’s critical listening room needed a vibration-free, solid platform to allow equipment to play under optimal conditions. In a challenging environment, full of hostile vibration, other equipment racks couldn’t deliver the desired result.
When designing Rack 1.3, 1.4 and 1.6, YG Acoustics™ adhered to its core values: straightforward, no-nonsense, precise science. The result is a rack series that isolates equipment from vibration extremely well. This is partly thanks to the fact that each shelf can be optimized in minutes for the weight of the specific component that it supports.
A video that demonstrates the effectiveness of YG Acoustics™ Rack 1.3 can be found here.
YG Acoustics™ Rack 1.3, 1.4 and 1.6 – straightforward, no-nonsense, precise science... handmade in U.S.A.
As with YG Acoustics™’ world-famous speakers, Rack 1.3, 1.4 and 1.6 are modular. The construction allows for the addition of shelves, and for horizontal expansion, without the need to replace the existing Rack.
Rack 1.3 - 3 shelves
Rack 1.4 - 4 shelves
Rack 1.6 - 6 shelves (3 high, 2 wide)
Other configurations available upon request
Internal width - 60 cm (23.6")
Internal depth - open construction, limited mainly by desired outer dimensions
Internal height - adjustable in 2.5 cm (1") increments
Unfirom load limit:
Bottom shelf - up to 97 kg (214 lbs)
Top/middle shelf - up to 61 kg (135 lbs)
Rack 1.3 - 59x65x54 cm (23x26x22") HxWxD
Rack 1.4 - 87x65x54 cm (35x26x22") HxWxD
Rack 1.6 - 59x127x54 cm (23x50x22") HxWxD
Rack 1.3 - 51 kg (112 lbs)
Rack 1.4 - 69 kg (152 lbs)
Rack 1.6 - 97 kg (213 lbs)
